Motorola SL1600 Two Way Radio

Name: Motorola SL1600 Two Way Radio
Brand: Motorola
SKU: SL1600
Price: 370.66 GBP
Availability: InStock

£308.88 Ex VAT £370.66 Inc VAT

The Motorola SL1600 2 way radio has been designed for easy, intuitive use. The side volume control, dedicated power button, prominent push-to-talk button, and top toggle channel switch have all been designed for quick one-hand access. Channel “fast toggle” allows users to scroll through 10 channels at a time.

This item is a licenced two-way radio. This means that you are required to have a valid OFCOM licence to use the radio in the UK. Using the radio without a licence is illegal. If you would like more information regarding OFCOM licences, please contact our service team by calling 0800 328 0100 or by emailing service@eemits.co.uk

FREE Next Day Delivery*

*Get FREE next day UK mainland delivery on orders over £50.

Programming Included

Hassle-free setup, ready to go.

The Motorola SL1600 delivers dependable push-to-talk communication in an ultra-slim and rugged form. Measuring just 22 mm thick, it fits easily into pockets or bags, curved edges and a stubby antenna prevent snagging or bulging.

Motorola SL1600 Key Features & Design

Simple one-hand operation: The Motorola SL1600 includes a side volume control, dedicated power button, prominent push-to-talk, and a top toggle channel switch—all designed to allow quick use with one hand.
Channel fast toggle: Users can scroll through 10 channels at a time for easier access.
Active View display: A shatterproof LED matrix display behind the housing shows channel, radio, and volume info. The display turns off when unused to save battery.
Range Max technology: Thanks to advanced radio design and a patented antenna, the SL1600 offers enhanced range while maintaining its slim profile and long battery life.
Dual Capacity Direct Mode: This uses the 2-slot TDMA DMR standard to double capacity in a 12.5 kHz channel—no repeater required.
Voice announcement: Audible prompts confirm operations, letting users keep eyes on the job.
Micro-USB connectivity: Simplifies charging and programming tasks.
Analogue + digital support: Works in both analogue and digital modes, making it adaptable to legacy systems and future upgrades.
Rugged & reliable: Rated IP54 for dust and splash resistance, and built to survive drops and tumbles. The radio endures Motorola’s Accelerated Life Test, simulating 5 years of hard use.

Performance & Specs

Battery life (05/05/90 duty cycle): Analog ~ 11.8 hours, Digital ~ 14 hours
Frequency ranges: VHF 136–174 MHz, UHF 403–470 MHz
Power output: 1W (minimum), up to 2W (analogue), up to 3W (digital)
Channels: 99 channels
Physical size / weight:
– Dimensions: 126 × 55 × 22 mm
– Weight (with standard battery): VHF: ~169 g / UHF: ~166 g

Technical Specification

Download the technical document.

Brands	Motorola
Battery Upgrades	No
Types of Radio	Hand Held Portable
Frequency Ranges	VHF: 136-174 MHz UHF: 403-470 MHz
Channel Capacities	99
Channel Spacings	12.5 kHz / 20 kHz / 25 kHz
Operating Voltages	3.7V (Nominal)
Types of Battery	Li-Ion (2300mAh) Battery
Battery Life (Digital)	14 Hours
Battery Life (Analogue)	11.8 Hours
Frequency Stability	± 1.5 ppm
Weight of Radio (includes battery and antenna)	VHF: 169g UHF: 166g
Dust & Water Instrusions	IEC60529 - IP54
Humidity	Per MIL-STD
Businesses	Yes
Ip Ratings	IP54
Displays	Half Key Pad
Sizes	Slim
Batteries	Li-Ion
Encryptions	Basic
Radio Models	SL1600
Dimensions	126 X 55 X 22 mm
Chargers	Single
RX Selectivity	60 dB (12.5 kHz)70 dB (20 / 25 kHz)
RX Intermodulations	65dB
Esd	IEC 61000-4-2 Level 3
Rx Spurious	≥ 70 dB
Radio Series	SL1600
Rx Hum and Noise	-40 dB @ 12.5 kHz -45 dB @ 20/25 kHz
Rx Audio Responses	TIA603D
Operating Temperatures	-30°C - +60°C
Storage Temperatures	-40°C - +85°C
Analogue Sensitivity	0.3 uV0.22 uV (typical) - @ 12dB SINAD
Rx Rated Audio Power Outputs	0.5 W (Internal)
Rx Radio Audio Distortions	5% (3% typical)
Rx Digital Sensitivity	0.25 uV0.19 uV (typical) - @ 5% BER
Licenced	Digital
Atex	No
Rx Conducted Spurious Emissions	< - 57 dBm
Product Statuses	Enquiry Only
